TH-55VF2 55" Ultra-Narrow Bezel Video Wall Display
An ideal solution to create large engaging video walls with an ultra-thin narrow frame and usage in digital signage, broadcast and control rooms.
Introducing one of the world's most seamless video walls with a 0.88mm bezel-to-bezel distance, high brightness, and 24/7 operation ready enabling a simplified and seamless multi-screen system for signage, events, and surveillance applications.
- 55" frameless D-LED LCD, 500 cd/m², 0.88 mm bezel to bezel, 24/7 operation, IPS panel with anti-glare surface (Haze 28%)
- Advanced uniformity for the best image quality
- DisplayPort UHD daisy chain functionality
- Durable failover and failback function with simplified workflow solution
- Supports reverse scan and frame control to improve multi-screen video visibility
Product Specifications
| SKU | TH-55VF2 |
|---|---|
| Weight | Approx. 23.0 kg (50.7 lbs) |
| Dimensions (W x H x D) | 1210.6 x 681.3 x 97.3 mm (47.658" x 26.820" x 3.829") |
| Brightness | 500 cd/m2 |
| Contrast Ratio | 1100:1 |
| Aspect Ratio | 16:9 |
| Response Time (G to G) | 8.0 ms |
| Viewing Angle (Horizontal/Vertical) | 178° / 178° (CR ≧ 10) |
| Effective Display Area (W x H) | 1209.6 x 680.3 mm (47.62" x 26.78") |
| Panel Type | IPS/D-LED |
| Screen Size (Diagonal) | 54.6" (1,387.8 ｍｍ) |
| Panel Surface Treatment | Advanced Anti-glare treatment (Haze 28%) |
| Resolution (H x V) | 1920 x 1080 |
| Dynamic Contrast Ratio | 500,000:1 |
| Speaker | ８Ω, 20 W [10 W ＋ 10 W]（10 % THD） |
| Digital Link | RJ45 x 1, Long Reach Mode (Shared with LAN IN） RJ45 x 1 (Shared with LAN OUT） |
